IBC MasterFill MF-10000 Series
Automated IBC Filling Line
End-to-End Automation • 25 IBCs/Hour • SIL-3 Safety
Technical Specifications
| Parameter | MF-1010 (Standard) | MF-1020X (ATEX) | MF-1030H (Heavy-Duty) |
|---|---|---|---|
| Capacity | 500-1000L (±0.15%) | 500-1000L (±0.2%) | 500-1000L (±0.18%) |
| Throughput | 25 IBCs/hour | 22 IBCs/hour | 20 IBCs/hour |
| Accuracy | ±0.15% gravimetric | ±0.2% | ±0.18% |
| Viscosity Range | 1-500,000 cP | 5-300,000 cP | 50-1,000,000 cP |
| Automation Level | AGV Loading + Robotic Sealing | Same + Gas Detection | Same + Abrasion Resistance |
| Filling Technology | Dual Coriolis Meters | ATEX Diaphragm Pumps | Heated Screw Conveyor |
| Material Contact | 316L SS + PTFE Lined | Hastelloy C276 | Hardox 500 + Ceramic Coating |
| VOC Control | >99.9% Carbon Adsorption | Thermal Oxidizer (99.99%) | Cryocondensation + Carbon |
| Changeover Time | <5 min (Auto-Tooling) | <7 min | <6 min |
| Power | 480V/60Hz, 18kW | 24VDC Ex ia | 480V/60Hz, 22kW |
| Line Length | 15m | 16m | 17m |
| Certifications | CE, ISO 9001 | ATEX Zone 0 | SIL-3 |
Integrated Line Components
| Module | Function | Technology |
|---|---|---|
| AGV Unloading | Pallet Transfer | Laser SLAM Navigation |
| IBC Cleaning | CIP/SIP Station | 360° Spray Heads (Ra<0.4μm) |
| Filling Station | Precision Dosing | Mass Flow Coriolis (±0.15%) |
| Headspace Control | N₂ Purging | O₂<0.5% Guarantee |
| Sealing System | Lid Placement & Torque | Servo-Driven Magnetic Gripper |
| Palletizing | Robotic Stacking | Fanuc M-20iD (0.02mm Accuracy) |
| Quality Control | Leak & Weight Verification | Helium Sniffer + Load Cells |
Core Innovations
1. SyncFlow™ Dual-Channel Filling
Performance Metrics:
| Metric | Performance | Industry Standard |
|---|---|---|
| Fill Speed | 300 L/min/nozzle | 150-200 L/min |
| Weight Variance | ±0.8% | ±2.5% |
| Flow Balance | 99.5% | 92-95% |
2. SmartSeal™ Containment System
Triple Barrier Protection:
金彩汇Inflatable PTFE Gasket
Vapor Recovery Hood (99.9% capture)
Negative Pressure Enclosure (-15Pa)
Leak Performance:
Test Method Result Helium Leak Test <10⁻⁹ mbar·L/s Bubble Emission Test 0 Bubbles/min (ISO 5208)
Industry-Specific Solutions
Chemicals & Solvents
| Feature | Specification |
|---|---|
| ATEX Zone 0 | Pressurized Cabinets (+50Pa) |
| Cross-Contamination | Dedicated Fluid Paths |
| Corrosion Resistance | Zirconium Flow Path |
Food & Pharma
EHEDG-Validated Design (EL Class I)
金彩汇21 CFR Part 11 Data Integrity
金彩汇Allergen Control Protocols
Paints & Coatings
| Challenge | Solution |
|---|---|
| Color Consistency | In-line Spectrophotometer (ΔE<0.4) |
| Settling | Pulsed Flow Agitation |
| Skin Formation | N₂ Blanketing (O₂<0.3%) |
Smart Control Ecosystem
15" IIoT HMI with LineOS™
AI-Driven Features:
Anomaly Detection:
Parameter Action Flow Imbalance >1% Auto-Calibration Seal Leak >0.1ml/min Emergency Shutdown Energy Optimization:
Mode Savings Idle 85% Power Reduction Partial Load Frequency Control
Certifications
► ATEX 2014/34/EU Cat.1 Zone 0 ► FDA 21 CFR 110/117 ► ISO 9001:2015 ► CE EN 415-7 ► SIL-3 (IEC 61511)
Operational Workflow
1. AGV IBC Infeed → 2. Auto-CIP Cleaning → 3. N₂ Purging (O₂<0.5%) → 4. Dual-Nozzle Filling (±0.15%) → 5. Lid Sealing (20-60 N·m) → 6. Helium Leak Test → 7. Robotic Palletizing → 8. Blockchain Documentation
Cycle Time: 2.4 min/IBC
Performance Validation
BASF Antwerp Report:
*"After 12 months operation:
Output金彩汇: 15 → 25 IBCs/hour (+67%)
Product Loss: 1.8% → 0.05%
VOC Emissions: ↓99.9% (EPA Method 21)
ROI: 8 months"*
